| Name | AlN/Aluminum nitride | |||
| Density | g/cm3 | 3.31 | ||
| Modulus of Elasticity | GPa | 310 | ||
| Fracture toughness | Mpa x m^1/2 | 3.5 | ||
| Poisons Ratio | – | 0.25 | ||
| Compressive Strength | MPa | 2100 | ||
| Flexural Strength | MPa | 335 | ||
| Hardness (Vickers) | GPa | 11 | ||
| Hardness (Knoop 100 g) | Kg/mm2 | 1170 | ||
| Name | AlN/Aluminum nitride | |||
| Maximum Temperature | Oxidizing | 750°C | Inert | 1300°C |
| Thermal Conductivity | @ 25°C | 180W/mK | @ 300°C | 130W/mK |
| Specific Heat | 760J/kg.K | |||
| Thermal Shock Resistance ΔT | 400°C | |||
| Coefficient of Expansion（10^-6/°C） | CTE 25°C ➞ 300°C | 4.6 | CTE 25°C ➞ 1000°C | 5.6 |
| Dielectric Constant | 8.6 （1 MHz） | |||
| Loss Tangent | 5×10^-4（1 MHz） | |||
| Volume Resistivity | 25°C | >10^13Ω cm | 500°C | 10^7Ω cm |
